Lincoln Electric IM10180 POWER FEED 25M NNS User Manual
Page 63
Control Box Assembly, Includes:
NSS
1
X
1
Control Box
G5584-8
1
X
2A
Control Box Decal
M22570
1
X
2B
Mast Decal (Not Shown)
M22570-1
1
X
2C
Insulation
S25126
1
X
3A
Wire Drive P.C. Board Assembly
S28539-[ ]
1
X
3B
#10-24 HLN
T9187-13
4
X
6A
Flex Tube
T10642-265
1
X
6B
Hose Clamp (Not Shown)
T13777-8
1
X
7A
Spindle & Mast Assembly (G5572-2)
See P-754-E
1
X
7B
#10-24 HLN
T9187-13
4
X
7C
Self Tapping Screw (Not Shown)
S9225-99
1
X
9
Insulated Mounting Block
M21096
1
X
10
Self Tapping Screw
S9225-99
2
X
11A
1/2-13 HN (Not Shown)
CF000027
1
X
11B
Plain Washer
S9262-80
1
X
11C
Lock Washer
E106A-15
1
X
11D
1/2-13 x 1.5 HHCS
CF000052
1
X
12
Bus Bar
M21006-6
1
X
12A
Sleeving (Not Shown)
E1159/B-.875-10.00
CS000902
1
X
13
Weld Cable, Includes:
M21463-4
1
X
13A
Cord Grip Connector
S19999
1
X
13B
Conduit Lock Nut
T14370-3
1
X
13C
Cam-Lok Welding Plug (Not Shown)
M25115
1
X
14
Harness (Not Shown)
G5599-2
1
X
15A
Solenoid Assembly
M17294-8
1
X
15B
Plain Washer (Not Shown)
S9262-149
1
X
15C
Conduit Lock Nut (Not Shown)
T14370-1
1
X
16A
Control Box Panel
S26587-7
1
X
16B
#10-24 HLN (Not Shown)
T9187-13
4
X
16C
Cable Connection Assembly
M21501-4
1
X
19
Resistor Bank Asbly, Includes:
NSS
1
X
19A
Resistor
S10404-95
2
X
19B
Resistor Bracket
M21144-1
1
X
19C
Insulating Washer
T4479-A
4
X
19D
Lock Washer (Not Shown)
T9695-1
2
X
19E
#10-24 x 5.00 RHS
CF000045
2
X
19F
Lock Washer
E106A-1
2
X
19G
#10-24 HN
CF000010
2
X
19H
Voltage Sense Select P.C. Board
M19540-[ ]
1
X
19J
Self Tapping Screw (Not Shown)
S9225-99
2
X
20
Shielding Gas Filter
S28863
1
X
22
Bypass Assembly (Not Shown)
S22969-12
1
X
25A Control Box Cover
M21011-2
1
X
25B Thread Forming Screw
S9225-99
4
X
26
Sems Screw (Not Shown)
T10082-12
1
X
Jan-14
POWER FEED
™
25M NNS
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-754-D.1
ITEM DESCRIPTION
PART NO.
QTY.
1 2 3 4 5 6 7 8 9
P-754-D.1
NSS - Not Sold Separately
