Case Front Assembly, Includes: NSS 1 X
1 Case Front G5577-5 1 X
2 Nameplate (G7937) NSS 1 X
3 Button Cover, Small S23055-1 12 X
4 Potentiometer Insulation S27401 1 X
5A User Interface P.C. Board S28540-[ ] 1 X
5B Sems Screw T10082-12 4 X
6 Shaft Seal T14034-4 2 X
7 Knob M22778-1 3 X
8 Switch, SPST T10800-71 1 X
9 Cam-Lok Receptacle, Includes: M25112 1 X
9A Conduit Lock Nut T14370-3 1 X
9B Plain Washer S9262-120 1 X
9C Lock Washer E106A-16 1 X
9D 3/8-16 Hex Jam Nut CF000121 1 X
10 Female Connector, Includes T14557-3 1 X
10A Lock Washer T9695-8 1 X
10B 1/2-13 Jam Nut CF000054 1 X
11 Receptacle, Includes: S25449 1 X
11A #6-32 HN CF000054 2 X
11B Lock Washer E106A-13 2 X
Jan-14
POWER FEED ™ 25M NNS
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-754-C.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-754-C.1
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
NSS - Not Sold Separately
