Lincoln Electric IM10073 OUTBACK 145 - Manual (Page 39)

Control Panel Assembly (G5959-5), Includes: NSS 1 X
1 Control Panel G5935-2 1 X
2A Receptacle S18907-4 1 X
2B Sems Screw T10082-30 4 X
3 Receptacle Cover M21760 1 X
4A Circuit Breaker M20585-2 1 X
4B Circuit Breaker Cover Seal S24911-2 1 X
4C Sems Screw (Not Shown) T10082-30 4 X
4D Lock Washer (Not Shown) T4291-A 4 X
5 Hour Meter - Snap In S17475-7 1 X
6A Output Terminal Assembly M13900-4 2 X
6B Self Tapping Screw S8025-91 4 X
6C 3/8-16 x .75 HHCS (Not Shown) CF000034 2 X
6D Plain Washer (Not Shown) S9262-76 2 X
6E Lock Washer (Not Shown) E106A-16 2 X
7A 1/4-20 HJLN T9187-1 1 X
7B 1/4-20 HN CF000017 1 X
8A Knob T10491-1 1 X
8B “O” Ring (Not Shown) T13483-7 1 X
9A Potentiometer T10812-110 1 X
9B #8-32 x .50 BR RHS (Not Shown) CF000102 3 X
9C Lock Washer (Not Shown) T9695-3 3 X
9D #8-32 BR HN (Not Shown) CF000103 6 X
10A Choke Assembly L13956-3 1 X
10B Self Tapping Screw (Not Shown) S9225-68 4 X
11A 120V Receptacle S20184 2 X
11B Receptacle Cover M16996 2 X
11C Receptacle Gasket S21088 2 X
11D Thread Forming Screw S9225-63 4 X
11E Speed Nut (Not Shown) T11525-1 4 X
12A Bridge Rectifier L11411-1 1 X
12C 1/4-20 x 1.00 HHCS (Not Shown) CF000014 4 X
12D Flat Washer (Not Shown) S9262-98 8 X
12E Lock Washer (Not Shown) E106A-2 4 X
12E 1/4-20 HN (Not Shown) CF000017 4 X
13 Nameplate L13690-1 1 X
14 Bushing T12380-1 2 X
15 Speed Nut T11525-5 5 X
20 Heat Shield S28647 1 X
25 Self Tapping Screw (Not Shown) S9225-68 4 X
28 Hang Tag (Not Shown) T11590-225 1 X
30A 1/4-20 HJLN T9187-1 1 X
30B Plain Washer (Not Shown) S9262-23 2 X
32A #10-24 HN CF000010 2 X
32B Plain Washer (Not Shown) S9262-27 1 X
32C Lock Washer (Not Shown) E106A-1 1 X
01-25-2011 OUTBACK ® 145
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-671-D.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-671-D.1
NSS - Not Sold Separately
