Lincoln Electric IM10134 COOL ARC 55 S WATER COOLER - Manual (Page 39)

Case Back Assembly (L15801-2), Includes: NSS 1 X
1 Rear Panel G5016-4 1 X
2A Input Cord S15254-20 1 X
2B Grommet T9274-2 1 X
3 Heat Exchanger M16385-6 1 X
5 Fan Shroud Assembly. Includes: L11536-1 1 X
5A Fan Shroud L11535-1 1 X
5B Fan M19076-4 1 X
5C Socket Head Cap Screw T9447-91 2 X
5D Lock Washer (Not Shown) T9695-3 2 X
5E Earth Ground Connection Decal T13260-4 1 X
5F Thread Forming Screw (Not Shown) S9225-99 4 X
6A Hose (.375 ID x .625 OD) T10642-338 1 X
6B Hose Clamp S10888-35 1 X
7A Hose (.375 ID x .625 OD) T10642-328 1 X
7B Hose Clamp S10888-35 1 X
8A #10-24 HN CF000010 2 X
8B Lock Washer (Not Shown) E106A-1 1 X
8C Ground Reference (Not Shown) S26124 1 X
10A Arclink Cable Assembly M22438 1 X
10B Grommet T9274-8 1 X
11 Receptacle Assembly, Includes: M20124-3 1 X
11A Connector (5 Socket) S12021-73 1 X
11B Capacitor (Not Shown) T11577-58 1 X
11C Self Tapping Screw (Not Shown) S8205-118 2 X
12A DC Relay S15122-14 1 X
12B Plain Washer (Not Shown) S9262-3 2 X
12C Lock Washer (Not Shown) T9695-3 2 X
12D #8-32 HN (Not Shown) CF000042 2 X
15 Thread Forming Screw S9225-99 4 X
16 Instruction Tag (Not Shown) T11590-191 1 X
17 Rating Plate (M22880-2) (Part of M22880) NSS 1 X
18 Wheeled Bin Decal T13086-201 1 X
COOL ARC ® 55 S
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-716-F.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-716-F.1
NSS - Not Sold Separately 11-27-2012
