Top Extrusion Assembly, Includes: L12757-1 1 X
1A Base Rail M21251-2 1 X
1B Bracket L15091-1 2 X
1C Thread Forming Screw S9225-99 4 X
1D Thread Forming Screw (Not Shown) S9225-99 8 X
2A Corner Cap L13138 4 X
2B Plain Washer S9262-182 12 X
2C Thread Forming Screw S9225-100 12 X
3A Front Mounting Bracket Assembly S28458 1 X
3B Rear Mounting Bracket Assembly S28459 1 X
3C Lock Washer (Not Shown) E106A-27 8 X
3E Torx Button Head Screw (Not Shown) S25930-3 8 X
5A Locking Bracket S28375 1 X
5B Lock Washer E106A-27 2 X
5C 1/4-20 x .75 HHCS CF000410 2 X
6A Roof L12763-5 1 X
6B Thread Forming Screw S9225-99 6 X
11 Wiring Diagram M22842 1 X
15 Arclink Feeder P.C. Board Assembly S29550-[ ] 1 X
11-27-2012 COOL ARC ® 55 S
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-716-D.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-716-D.1
NSS - Not Sold Separately
Note : When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
