Lincoln Electric IM10134 COOL ARC 55 S WATER COOLER - Manual (Page 33)

Case Front Assembly, Includes: L16078-1 1 X
1 Case Front Welded Assembly G5015-4 1 X
2 Nameplate L15996-2 1 X
3A Quick Connect (Female) and Nut S19664-1 2 X
3B Lock Washer E106A-12 2 X
4A Hose T10642-326 1 X
4B Hose Clamp (Not Shown) S10888-35 1 X
5A Hose T10642-337 1 X
5B Hose Clamp (Not Shown) S10888-35 1 X
6 Plug & Lead Assembly (LED), Includes: S18250-1013 1 X
6A LED Panel Mount Assembly (Not Shown) S23740-3 1 X
6B LED, Bi-Color (Not Shown) (Not Shown) T13657-7H24 1 X
6C LED Lens - Clear, Includes “O” Ring S23093-1 1 X
6D “O” Ring S23094-1 1 X
7 Toggle Switch T10800-49 1 X
10 Thread Forming Screw (Not Shown) S9225-99 4 X
11A Thread Forming Screw (Not Shown) S9225-99 4 X
11B Hose Clamp S10888-35 1 X
12A Right Case Side L12742-1 1 X
12B Thread Forming Screw S9225-99 4 X
13 Logo Decal S11893-13 2 X
14A Left Case Side L12752-1 1 X
14B Thread Forming Screw (Not Shown) S9225-99 4 X
15 Warning Decal (M22880-1) (Part of M22880) NSS 1 X
17A Lead Clamp T12563-10 4 X
17B Thread Forming Screw (Not Shown) S9225-99 4 X
20 Connector (Shipped Loose) (Not Shown) T14557-27 2 X
21 Flow Switch S29548 1 X
11-27-2012 COOL ARC ® 55 S
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-716-C.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-716-C.1
NSS - Not Sold Separately
