Lincoln Electric IM10153 CLASSIC 300 HE - Manual (Page 57)

1A Door L6659-G 2 X
1B Door Hinge Pin S20295 4 X
1C Retaining Ring S9776-62 8 X
2 Door Bumper (Mounts in Roof) T15154 4 X
3 Door Hook Assembly S10656-3 1 X
3A Door Hook Assembly (Not Shown) S10656-1 1 X
4 Door Hook Assembly S10656-4 1 X
4A Door Hook Assembly (Not Shown) S10656-2 1 X
5A Door Hook Washer T10878 4 X
5B Self Tapping Screw S8025-92 8 X
6A Door Support Rod M16696 2 X
6B Speed Clip T10982-7 2 X
7A Door Support Bracket S20289 2 X
7B 1/4-20 x RHS CF000012 4 X
7C Lock Washer E106A-2 4 X
7D 1/4-20 HN CF000017 4 X
8A Door Bumper (Mounts to Door) S21463 8 X
8B Plain Washer S9262-98 8 X
8C Rivet M8834-1 8 X
8D Speed Clip T10982-7 8 X
9A Spring Clip S20290 2 X
9B Lock Washer T9695-1 2 X
9C #10-24 x .312 PPHS CF000335 2 X
9D #10-24 HLN T9187-9 2 X
10A Roof L5193-5 1 X
10B Roof Mounting Angle (Radiator End) S13593 2 X
10C 5/16-18 x 1.50 SQHS CF000258 2 X
10D 5/16-18 HLN T9187 2 X
10E Roof Mounting Angle (Control Panel End) (Not Shown) T9428 2 X
10F 5/16-18 x 1.25 SQHS (Not Shown) CF000180 2 X
10G 5/16-18 HLN (Not Shown) T9187 2 X
11 Wiring Diagram M24680 1 X
12 Logo Decal S27368-6 2 X
13A Fuel Warning Decal T13086-205 1 X
14 Warning Decal M16197 1 X
15 Door Catch Decal T11030 2 X
16 Engine Service Decal S29892 1 X
17 Engine Instruction Tag (Not Shown) M17238 1 X
18 Warning Decal S25896 1 X
19 CO Warning Decal M21436 1 X
21 Green Initiative Decal S28039-4 1 X
05-13-2013
CLASSIC ® 300 HE ®
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-734-L.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-734-L.1
