Lincoln Electric IM10153 CLASSIC 300 HE - Manual (Page 39)

Upper Control Panel Asbly (M22865), Includes: NSS 1 X
1 Upper Control Panel M22863 1 X
2 Rheostat M5090-C 1 X
Sems Screw (Not Shown) T10082-4 2 X
3 Selector Switch Assembly M13335 1 X
#10-24 x 1.75 RHS CF000127 2 X
Spacer S10918-60 2 X
Plain Washer S9262-27 2 X
Lock Washer T9695-1 2 X
#10-24 HN CF000010 2 X
4 Nameplate L16112 1 X
5 Fastener Button T14659-2 1 X
8 Rheostat Handle S16664-13 1 X
9 Control Handle M13989-1 1 X
05-13-2013
CLASSIC ® 300 HE
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-734-C.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-734-C.1
NSS - Not Sold Separately
