Lincoln Electric IM10153 CLASSIC 300 HE - Manual (Page 42)

16F #4-40 HN (Not Shown) CF000002 1 X
18 MOV Assembly (Not Shown) S28445 1 X
19 Receptacle & Lead Assembly (Not Shown) S14165-472 1 X
20 Plug & Lead Assembly (Not Shown) S14165-473 1 X
21A Engine Control Unit * 1 X
21B Plain Washer (Not Shown) S9262-27 4 X
21C Lock Washer (Not Shown) T9695-1 2 X
21D #10-24 HN (Not Shown) CF000010 2 X
21E Space (Not Shown) S10918-69 2 X
21F #10-24 x 2.75 RHS (Not Shown) CF000049 2 X
22A Current Sensor P.C. Board S25590-2 1 X
22B Self Tapping Screw (Not Shown) S8025-97 2 X
23A Lower Control Nameplate L16333 1 X
23B Fastener Button T14659-2 4 X
29A Thread Forming Screw (Not Shown) S9225-26 4 X
29B Lock Washer (Not Shown) T9860-3 4 X
31 3 Year Warranty Decal (Not Shown) S22127-3 1 X
33A Guard (Not Shown) M24952 1 X
33B Thread Forming Screw (Not Shown) S9225-8 2 X
34A Guard (Not Shown) M24953 1 X
34B Thread Forming Screw (Not Shown) S9225-8 2 X
35 Harness (Not Shown) G7518 1 X
05-13-2013
CLASSIC ® 300 HE
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-734-D.2
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-734-D.2
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
* Contact Engine Manufacturer
