1A Case Side (Left) G6450 1 X
1B Nut Retainer (Not Shown) T10097-3 2 X
1C Self Tapping Screw S9225-68 6 X
1D Self Tapping Screw S9225-66 4 X
1E Plain Washer (Not Shown) S9262-183 4 X
1F Case Side (Right) G6451 1 X
2A Roof G6452 1 X
2B Self Tapping Screw (Not Shown) S9225-68 8 X
5 Wiring Diagram G6890-7 1 X
6 Warranty Decal S22127-2 1 X
7 Green Initiative Decal S28039-2 1 X
8 Lincoln Logo Decal S27368-4 2 X
9 Flextec Decal M22461 2 X
10 Warning Decal L8064-1 1 X
02-04-2013 FLEXTEC ™ 450
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-732-G.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
