Base & Center Assembly, Includes:
G6490-4
1
X
1
Base
G6446
1
X
2A
Corner Cap
L13138
4
X
2B
Plain Washer
S9262-183
6
X
2C
Self Tapping Screw
S9225-66
6
X
3A
Mounting Washer
T9764-6
4
X
3B
Resistor
S10404-139
2
X
3C
Carriage Bolt (No Shown)
T11827-59
2
X
3D
Plain Washer
S9262-98
2
X
3E
Lock Washer
E106A-2
2
X
3F
1/4-20 HN
CF000017
2
X
6A
Shunt
S6602-30
1
X
6B
Carriage Bolt
T11827-26
1
X
6C
Plain Washer (Not Shown)
S9262-30
1
X
6D
Lock Washer (Not Shown)
E106A-3
1
X
6E
5/16-18 HN (Not Shown)
CF000029
1
X
7A
Thread Forming Screw
S9225-95
2
X
7B
Plain Washer (Not Shown)
S9262-27
2
X
7C
Lock Washer (Not Shown)
E106A-1
2
X
7D
#10-24 HN (Not Shown)
CF000010
2
X
8A
Choke Assembly
L15821
1
X
8B
Thread Forming Screw
S9225-66
4
X
8C
Plain Washer
S9262-98
4
X
Connects Choke Coil to Output Stud:
9A
Carriage Bolt (Not Shown)
T11827-26
1
X
9B
Plain Washer (Not Shown)
S9262-30
1
X
9C
Lock Washer (Not Shown)
E106A-3
1
X
9D
5/16-18 HN (Not Shown)
CF000029
1
X
10A
Output Rectifier Sub Assembly
L15816
1
X
10B
Self Tapping Screw (Not Shown)
S9225-68
2
X
11A
Transformer Assembly
G6453
1
X
11B
Self Tapping Screw (Not Shown)
S9225-68
4
X
13A
5/16-18 x 1.25 HHCS
CF000028
2
X
13B
Plain Washer (Not Shown)
S9262-30
4
X
13C
Lock Washer (Not Shown)
E106A-3
2
X
13D
5/16-18 HN
CF000029
2
X
15A
Switch Board Assembly
G7485
1
X
15B
Self Tapping Screw
S9225-65
2
X
02-04-2013
FLEXTEC
™
450
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-732-E.1
ITEM DESCRIPTION
PART NO.
QTY.
1 2 3 4 5 6 7 8 9
P-732-E.1
NSS - Not Sold Separately
