Lincoln Electric IM10062 FLEXTEC 450 - Manual (Page 43)

08-15-2012 FLEXTEC ™ 450
Do Not use this Parts List for a machine if its code number is not listed. Contact the Service Department for any
code numbers not listed.
Use the Illustration of Sub-Assemblies page and the table below to determine which sub assembly page and
column the desired part is located on for your particular code machine.
P-652-A.1 P-652-A.1
Flextec ™ 450
For Codes: 11626, 11754 & 11941
CODE NO.
11626 1 1 1 1 1
11754 1 2 1 1 2
11941 2 3 2 2 3
W
raparound Assembly
P-652-G
5
Case Back
Assembly
P-652-F
4
Base & Center
Assembly
P-652-E
3
Divider Panel
Assembly
P-652-D
2
Case Front
Assembly& Door
P-652-C
1
SUB ASSEMBLY
PAGE NAME
PAGE NO.
Sub Assembly Item
No.
