AFL-08B-N270 User Manual
Page 18
Specifications AFL-08B-N270
Bluetooth V2.0 Yes (via internal USB interface)
Construction Material ABS + PC Plastic front frame
LED Function One Power ON/OFF LED on Front Panel
Mounting Panel, Wall, Rack, Arm, Stand (VESA 75mm x 75mm)
Front Panel Color Grey 7539U
Dimension (W x H x D mm) 234 x 184 x 42
Operation Temperature (ºC) -10ºC~50ºC
Storage Temperature (ºC) -20ºC~60ºC
Net Weight 0.8 Kg
IP Level Front Frame IP64
EMC CE, FCC, CCC
Safety CB
Touch Screen Resistive 5-Wire
Power Adapter
36W Power Adapter
90VAC~264VAC, 50/60Hz, 12VDC
12VDC output
Power Requirement 12VDC
Power Consumption 25W
Table 1-1: AFL-08B-N270 Specifications
1.5 Dimensions
The AFL-408A/B-N270 dimensions are listed below and shown in the following figure.
Width: 234 mm
Height: 184 mm
Depth: 42 mm
