AFL-08B-N270 User Manual
Page 17
1.4 System Specifications
The technical specifications for the AFL-08B-N270 systems are listed below.
Specifications AFL-08B-N270
LCD Size 8"
Max Resolution 800 x 600
Brightness (cd/m2) 300
Contrast Ratio 400:1
LCD Color 262K
Pixel Pitch (mm) 0.0675(H) x 0.2025(V)
Viewing Angle (H-V) 130º/120º
Backlight MTBF 30000 hrs
SBC Model AFLMB-945GSE-R10
CPU Intel® Atom™ N270 1.6 GHz CPU
Chipset Intel 945GSE + ICH7M
RAM
1 GB 533MHz DDR2 SO-DIMM
Supports one 400MHz or 533MHz DDR2 SO-DIMM (2 GB
Max.)
I/O Ports and Switches
One 12V DC power jack
One Audio line-out jack
One External SATA port
One Power switch
One Reset button
Two RJ-45 GbE LAN ports
One RS-232 serial port
One RS-232/422/485 serial port
Two USB 2.0 ports
SSD CF Type II
Watchdog Timer Software programmable supports 1~255 sec. System reset
Audio
AMP 1.5W + 1.5W internal speakers
Digital microphone
Digital Camera 300K pixel
Wireless LAN Wireless LAN 802.11 b/g PCIe mini card module
