AFL-xxA-N270 Series Panel PC

Page 141

8.4.2 Inverter Power Selection Jumper (JP12)

Pin Description

Short 1-2

+12 V (Default)

Short 3-4

+5 V

Short 5-6

+3.3 V

Table 8-33: Inverter Power Selection Jumper (JP12) Settings

8.4.3 LVDS Panel Voltage Selection Jumper (J_VLVDS1)

Pin Description

Short 1-2

+3.3 V (Default)

Short 2-3

+5 V

Table 8-34: LVDS Voltage Selection Jumper (J_VLVDS1) Settings

8.4.4 MCU LCD Type Selection Jumper (JP14)

Pin Description

Short 1-3

LCD Panel (Default)

Short 2-4

LED Panel

Table 8-35: MCU LCD Type Selection Jumper (JP14) Settings

8.4.5 MCU PWM Power Selection Jumper (JP13)

Pin Description

Short 1-2

+5V (Default)

Short 2-3

+3.3V

Table 8-36: MCU PWM Power Selection Jumper (JP13) Settings

8.4.6 Panel Type Selection Jumper (J_LCD_TYPE1)

Pin Description Pin Description

1 PA_DGPI0 2 GND

3 PA_DGPI1 4 GND
