IEI Integration AFL-W10A-N270 v1.00 - Manual (Page 18)

AFL-W10A-N270 User Manual
Page 18
Specifications AFL-W10A-N270
LED Function One Power ON/OFF LED on Front Panel
Mounting
Panel, Wall, Rack, Arm, Stand (VESA 75mm x 75mm /
100mm x 100mm)
Front Panel Color Grey 7539U
Dimension (W x H x D mm) 280 x 251 x 49
Operation Temperature (ºC) -10ºC~50ºCD
Storage Temperature (ºC) -20ºC~60ºC
Net Weight 1.4 Kg
IP Level Front Frame IP64
EMC CE, FCC, CCC
Safety CB
Touch Screen Resistive 5-Wire
Power Adapter
48W Power Adapter
90VAC~264VAC, 50/60Hz, 12VDC
Power Requirement 12VDC
Power Consumption 28W
Table 1-1: AFL-W10A-N270 Specifications
1.5 Dimensions
The AFL-408A/B-N270 dimensions are listed below and shown in the following figure.
Width: 280 mm
Height: 251 mm
Depth: 49 mm
