IMBA-Q670 ATX Motherboard
Page 107
5.4.2.2 NB PCIe Configuration
Use the NB PCIe Configuration submenu (BIOS Menu 25) to configure the northbridge
PCIe settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PCIEX16_1 Not
Present
PCIEX16_1-Gen X [Auto]
Enable PEG [Auto]
Detect Non-Compliance Device [Disabled]
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 25: NB PCIe Configuration
Î PCIEX16_1-Gen X [Auto]
Use the PCIEX16_1-Gen X option to configure PEG0 B0:D1:F0. Configuration options are
listed below.
ƒ Auto Default
ƒ Gen1
ƒ Gen2
ƒ Gen3
Î Enable PEG [Auto]
Use the Enable PEG option to enable or disable PEG.
Î
Disabled Disables PEG.
Î
Enabled Enables PEG.
Î
Auto D EFAULT Automatically detect PEG
