IMBA-Q670 ATX Motherboard
Page 101
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
> PCH-IO Configuration
> System Agent (SA) Configuration
PCH Parameters.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19: Chipset
5.4.1 PCH-IO Configuration
Use the PCH-IO Configuration menu (BIOS Menu 20) to configure the PCH chipset.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled (ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCH Azalia Configuration
Power Saving Function(ERP) [Disabled]
Enable to reduce power
consumption in system
off state.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: PCH-IO Configuration
