IMBA-Q670 ATX Motherboard
Page 97
5.3.10.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 16) to configure smart
fan temperature and speed settings.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
CPU_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
CPU Temperature 1 60
CPU Temperature 2 50
CPU Temperature 3 40
CPU Temperature 4 30
SYS_FAN1 Smart Fan control [Auto Duty-Cycle Mode]
System Temperature 1 60
System Temperature 2 50
System Temperature 3 40
System Temperature 4 30
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: Smart Fan Mode Configuration
Î CPU_FAN1 Smart Fan control [Auto by Duty-Cycle Mode]
Use the CPU_FAN1 Smart Fan control option to configure the CPU Smart Fan.
Î
Manual Duty
Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
Î
Auto Duty-Cycle
Mode
D EFAULT The fan adjusts its speed using Auto by
Duty-Cycle settings
Î SYS_FAN1 Smart Fan control [Auto by Duty-Cycle Mode]
Use the SYS_FAN1 Smart Fan control option to configure the system Smart Fan.
Î
Manual Duty
Mode
The fan spins at the speed set in Manual by Duty
Cycle settings
