Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Core(TM) i5-2400 CPU 0 @ 3.10GHz
CPU Signature
206a7
Microcode Patch 14
Max CPU Speed 3100 MHz
Min CPU Speed 1600 MHz
Processor Cores 4
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Intel SMX Technology supported
L1 Data Cache
32 kB x 4
L1 Code Cache 32 kB x 4
L2 Cache 256 kB x 4
L3 Cache 6144 kB
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: CPU Information
The CPU Configuration menu (BIOS Menu 7) lists the following CPU details:
ƒ Processor Type: Lists the brand name of the CPU being used
ƒ CPU Signature: Lists the CPU signature value.
ƒ Microcode Patch: Lists the microcode patch being used.
ƒ Max CPU Speed: Lists the maximum CPU processing speed.
ƒ Min CPU Speed: Lists the minimum CPU processing speed.
ƒ Processor Cores: Lists the number of the processor core
ƒ Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
ƒ Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
ƒ Intel SMX Technology: Indicates if Intel SMX Technology is supported by the
CPU.
ƒ L1 Data Cache: Lists the amount of data storage space on the L1 cache.
ƒ L1 Code Cache: Lists the amount of code storage space on the L1 cache.
ƒ L2 Cache: Lists the amount of storage space on the L2 cache.
ƒ L3 Cache: Lists the amount of storage space on the L3 cache.
