IMBA-9454 Motherboard
Page 33
Connector
Type
Label
Audio connector
7-pin header
CN4
Auxiliary audio connector
4-pin header
AUX1
CD-in connector
4-pin header
CD_IN1
CompactFlash connector
50-pin CF slot
CF1
Digital input/output connector
10-pin header
DIO1
Fan connector - CPU
4-pin wafer
FAN1
Fan connector - System
3-pin wafer
FAN2
Fan connector - System
3-pin wafer
FAN3
Floppy disk drive connector
34-pin box header
FDC1
Front panel audio connector
10-pin header
CN3
IDE Interface connector
40-pin box header
IDE1
Infrared connector
5-pin header
IR1
Multi-panel connector
14-pin header
CN2
PCI Express x16 slot
82-pin PCIe x16 slot
PCIE2
PCI Express power connector
4-pin wafer
PCN1
PCI slot
124-pin PCI slot
PCI1
PCI slot
124-pin PCI slot
PCI2
PCI slot
124-pin PCI slot
PCI3
PCI slot
124-pin PCI slot
PCI4
PCI slot
124-pin PCI slot
PCI5
PCI slot
124-pin PCI slot
PCI6
SATA drive connector
7-pin SATA
SATA1
SATA drive connector
7-pin SATA
SATA2
SATA drive connector
7-pin SATA
SATA3
SATA drive connector
7-pin SATA
SATA4
Serial port connector (RS-232)
10-pin box header
COM3
Serial port connector (RS-232)
10-pin box header
COM4
