IMB-Q670 Micro-ATX Motherboard
Page 79
 L2 Cache: Lists the amount of storage space on the L2 cache.
 L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.4 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode [AHCI Mode]
SATA Port0
Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port1 Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port2
Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port3
Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port4
Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
SATA Port5
Not Present
Staggered Spin-up [Disabled]
External SATA Port [Disabled]
Hot Plug [Disabled]
(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
