IMB-Q670 Micro-ATX Motherboard
Page 106
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Auto Power Button Status [OFF]
USB Controller [Enabled]
On-Chip GbE Configuration
GbE Controller [Enabled]
GbE PXE Boot [Disabled]
Wake Event Configuration
Restore AC Power Loss [Power Off]
Resume on PCIE Wake [Enabled]
Resume on PME/GbE [Enabled]
Resume on Ring [Enabled]
Resume on PS/2 [Enabled]
Audio Configuration
Azalia HD Audio [Enabled]
Azalia internal HDMI codec [Enabled]
PCI Express Ports Configuration
PCIe x4 Slot [Enabled]
PCIe LAN Controller [Enabled]
PCIe LAN PXE Boot [Disabled]
PCIe USB3.0 Controller [Enabled]
PCIe x8 Slot (PCIe x1) [Enabled]
Enabled/Disabled All USB
controllers
---------------------
: Select Screen
 : Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: Southbridge Chipset Configuration
 USB Controller [Enabled]
Use the USB Controller option to enable or disable USB controller function.

Disabled All USB controllers disabled

Enabled D EFAULT All USB controllers enabled
 GbE Controller [Enabled]
Use the GbE Controller option to enable or disable the GbE controller. Before disabling
the GbE controller, the AMT function must be disabled.

Disabled The onboard GbE controller is disabled
