IMB-Q670 Micro-ATX Motherboard
Page 8
Specification/Model IMB-Q670
Ethernet Two RJ-45 ports
Keyboard/Mouse Dual PS/2 port
TPM 2 x 10-pin pin header
Serial Ports One external RS-232 serial port
One RS-422/485 via internal box pin headers
Eight RS-232 via internal box pin headers
USB ports Two external USB 2.0 ports on rear IO
Two external USB 3.0 ports on rear IO by NEC D720200F1
Eight internal USB 2.0 ports by pin header
Serial ATA Four SATA 3Gb/s channels with 3.0 Gb/s data transfer rates
Two SATA 6Gb/s channels with 6.0 Gb/s data transfer rates
Environmental and Power Specifications
Power Supply ATX/AT supported
Power Consumption [email protected], [email protected] , [email protected], [email protected], [email protected]
(Intel® 2.60GHz CPU with 1333MHz DDR3 4GB x 4 Memory)
Operating temperature -20ºC ~ 60ºC/-4°F ~ 140°F
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 244 mm x 244 mm
Weight GW/NW 1200 g / 680 g
Table 1-1: IMB-Q670 Specifications
