E Series - 12 Lead ECG Monitoring Option Insert
14 9650-1213-01 Rev. G
FAX NO CARRIER or MUSE NO CARRIER
message is displayed. Receiving phone line is not picking up or the sending modem is
experiencing problems. The E Series automatically attempts to
transmit until the transmission is successful or the E Series operator
presses the Abort softkey.
If retransmission fails:
• Check the modem connection to the E Series unit.
• Power cycle the cellular phone.
• If transmitting to a MUSE system and multiple MUSE phone
numbers are configured, press the Abort softkey and follow steps
to attempt to transmit to another number.
• If transmitting to a MUSE system, check that the MUSE system’s
phone numbers are set up correctly. For more information, see
the E Series Configuration Guide.
FAX NO DIAL TONE or MUSE NO DIAL TONE
message is displayed.
• Check the modem connection to the E Series unit.
• Check the modem connection to the phone jack or cellular phone.
• Power cycle the cellular phone.
MODEM REQUIRED message is displayed. No PCMCIA modem card is present. Insert PCMCIA modem card
and repeat transmission attempt.
MUSE CANCEL message is displayed. The E Series operator pressed the Abort softkey or turned the
selector switch to DEFIB or PACER.
MUSE DATA NOT VALID message is
displayed. An overriding activity, such as an alarm situation, preempted data in
the process of being saved to the E Series unit. The data is
incomplete or corrupted.
Re-acquire 12-lead data, and attempt to retransmit.
DATA NOT READY / SEND FROM PAT. REC.
message is displayed. 12-lead data is not yet ready for transmission. Select the 12-lead
record from the Patient Records screen and retransmit.
Symptom Recommended Action
