Vestil WT-2424 & WT-2221 - Manual (Page 3)

3
Lightly oil screws #8 and #12
semiannually or as required.
PARTS IDENTIFICATION FOR WT-2424
QUANTITY
1
1
1
4
4
1
1
1
1
1
2
1
1
3
1
1
4
2
2
2
1
1
1
1
A/L Available at local hardware store
DESCRIPTION ITEM NO. ENGINEER NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19A
20
21
22
23 16-513-003
37024
11115
11003
33208
16-526-002
16-514-017
16-526-001
16-110-001
16-020-002
16-145-006
16-026-002
16-110-002
64137
KNOB 2-5
16-514-024
REC -1-1½ x 3-11GA
01-111-037
16-132-002
16-132-003
16-645-005
16-042-002
16-042-001
16-042-002 Tabletop Weldment
3/8-16" Nylok Nut
3/8-16 X 3" UNC H.H.C.S.
1/4-20 X 1/2" UNC H.H.C.S.
1/4" I.D. X 1-1/4" O.D. Fender Washer
Tilt Boss Sub Assembly
Inner Upright
Tilt Thread
1/2" I.D. Thrust Bearing
Pivot Boss
Handwheel / Crank
Elevating Thread
3/4" I.D. Thust Bearing
3/16" x 1-1/2" Spring Pin
Locking Screw, Height Adjustment
Base Assembly
Plastic End Cap, Base Tube
7/8" I.D. x 1-1/8" O.D. Brass Bushing
3" Swivel Caster w/brake
3" Swivel Caster
Crank Rod
Elevating Thread Sprocket
#40 Standard Roller Chain
Sprocket Weldment
PART NO.
WT-TAB
A/L
A/L
A/L
A/L
WT-TBA
WT-IU
WT-TT
WT-.5TB
WT-PB
WT-HC
WT-ET
WT-.75TB
A/L
WT-LS
WT-BA
WT-PC
WT-BB
WT-SC/B
WT-SC
WT-CR
WT-ETS
WT-RC
WT-SP
