Vestil SP-TOP - Manual

08/28/06 drb Manual, trailer stabilizing jacks, 13126120.doc
V ESTIL M FG . C O . 1
V ESTIL M ANUFACTURING C ORP .
2999 N. Wayne St., Angola, IN 46703
Ph: 260-665-7586 · Fax: 260-665-1339
E-mail: [email protected] · Website: www.vestil.com
T
RAILER
S
TABILIZING
J
ACKS
(Models BFSJ-2748, LO-J-BEAM, H-LO-J-BEAM, LO-J, HI-J, SP-TOP, SP-TOP-R, SJ-35, SJ-35-EF)
User Instructions ..........……………………….……… 2
Routine Maintenance & Safety Checks …………….... 3
Exploded Structural Parts Drawing & BOM ………... 4-7 Safety Label Identification .............................................7
Warranty …………………………………….……..…. 8
I MPORTANT N OTES , W ARNINGS AND S AFETY I NSTRUCTIONS
Ensure that all employees understand and follow the following.
* Failure to read and understand this owner’s manual before using or
servicing any model of trailer stabilizing jack constitutes a misuse of
the product. All persons who will use or care for this product must be
familiar with this material.
o
Any load must be removed from the jack before performing repairs or
maintenance.
o
Ensure that all of the information / safety / warning labels stay in place
and remain legible.
o
Do not use the trailer stabilizing jack if any damage is observed.
o Trailer stabilizing jacks are intended to be used only on compacted,
improved surfaces to support the ends of semitrailers to help prevent
tipover during loading and unloading of the trailer.
o
If oil is needed (H-LO-J-BEAM only), use a mineral-based hydraulic oil
with a viscosity grade of 75 SUS at 100°F, (ISO 15 cSt @ 40°C).
♦ Do not perform any modifications to a trailer stabilizing jack without the
manufacturer’s approval. Failure to receive authorization for changes to
the equipment could void the warranty.
♦ Maintenance and repairs are to be done only by personnel qualified to
perform the required work. Consideration will not be given for warranty
repair charges without prior written authorization by the manufacturer.
WHEN ORDERING
REPLACEMENT PARTS :
We take pride in using quality
parts on the equipment we
manufacture. We are not
responsible for equipment
problems resulting from the use
of unapproved replacement
parts.
To order replacement or
spare parts for this equipment,
contact the factory.
R ECEIVING INSTRUCTIONS
It is possible that this product
could incur damage during
transit.
Inspect the unit closely when
it arrives. If you see evidence
of damage or rough handling to
either the packaging or to the
product when it is being
unloaded, immediately make a
note of it on the Bill Of Lading!
It is important that you
remove the product’s packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
O
WNER
’
S
M
ANUAL
BFSJ-2748
SJ-35
LO-J & SP-TOP-R
H-LO-J-BEAM
