Parts list – Vestil RR Series User Manual

Page 4

PARTS LIST

ITEM NO.

1
2
3
4
5
6
7
8

N/S

10
11
12
13
14
15
17
18
19
20
21
22

N/S
N/S
N/S
N/S
N/S
N/S
N/S
N/S

PART NUMBER

D-COMP
D-TR
D-TRPB
D-CBS
D-CBSB-**
D-URP
D-LRP
D-REL-CH
D-REL-RF-KIT
D-UTLP
D-LTLP
D-UPLP
D-CY
D-W
D-TPIN
D-CTP
D-TC
D-SS
D-BPIN
D-LR
D-LS
D-LAM
HNG-CST
DM2-6-HP
DM2-7-HP
D-LAM-LP
DM2-**-**-20,000LA
DM2-**-**-50,000LA
DM2-**-TTG
D-ES-SPG

DESCRIPTION

Ratchet Hold Down Assembly (38 lbs.)
Trunion
Trunion Pillow Block Bearings
Counter Balance Springs
Spring Bolt (must have dock model #)
Upper Ratchet Pin
Lower Ratchet Pin
Release Chain
Release Chain Retrofit Kit with Rollers
Upper Trunion Link Pin
Lower Trunion Link Pin
Upper Link Pin (lip kick mech.)
Lip Cylinder (shock absorbers)
Washer
Top Cylinder Pin
Cotter Pin
Lip Trip Cable with Spring
Spring Shackle
Bottom Cylinder Pin
Lip Rod
Lip Spring
Complete Lip Actuating Mechanism
Hinge Block (Casting Weldment)
Hinge Pin for 6’ Wide Leveler
Hinge Pin for 7’ Wide Leveler
Lip Post for Actuating Mech.
Lip Assembly (Must have length + width)
Lip Assembly (Must have length + width)
Telescopic Toe Guard (Must have model number)
Emergency Stop Return Spring
