Page 3-1
3
LED Indicators
The front panel LEDs visually indicate the power, port activity and status. If the
LED indicators do not correspond to the activities listed in this chapter, refer to
Appendix A: Troubleshooting.
Figure 3-1 FH208B Front Panel LED
(Similar to FH208 front panel)
Figure 3-2 FH216B Front Panel LED
(Similar to FH216 front panel)
FriendlyNet
FH208B
Link/Act
100Mbps/
1
2
3
4
5
6
7
8
8-port Dual-speed Ethernet Hub
Auto
Power
Switch
Collision
10 100
FriendlyNet
FH216B
Link/Act
100Mbps/
1
2 3
4
5
6
7
8
9
10
11
12
13
14
15
16
16-port Dual-speed Ethernet Hub
Auto
Power
Switch
Collision
10 100
