O PERATION I NSTRUCTIONS – DGD-A / DGS-A
o Ensure that all employees involved in the operation of this DGD-A or DGS-A understand and follow these
instructions!
o Modifications or additions to the DGD-A / DGS-A without prior manufacturer’s authorization may void the
Drum Gripper’s warranty.
The standard model DGD-A / DGS-A is suitable for lifting and transporting open or closed standard 30 gallon and 55-
gallon steel drums in most (non classified) industrial locations which do not involve hazardous materials.
Loading and Operation:
The load rating, in pounds, is shown on the machine data plate. It indicates the net capacity of the DGD-A / DGS-A
with a static load that is centered and evenly distributed.
1.) Adjust the forks so that the inside width between the forks will fit into the fork pockets. One fork must be
locked to the bed plate.
2.) Drive the truck forward to slip forks into the fork sleeves. Attach safety chain the mast to secure drum lifter
to forks.
3.) Raise the unit and tilt the forks forward to separate the arms slightly.
4.) Lower the unit over the top of the drum until the arms are at the desired lifting point on the drum.
5.) Raise the forks and tilt them back keeping the drum as close to the floor as possible while transporting.
6.) To release the drum, tilt the forks forward, lower drum to the ground and back away from the drum.
Note: The addition of any ancillary equipment to the DGD-A / DGS-A by third parties must be taken into account when
determining the maximum working load.
Warning: Do not exceed the DGD-A / DGS-A’s load ratings. Injury to personnel or permanent damage to the loading
arms, the drum(s), or drum contents, could result from exceeding the listed capacity.
Inspect the safety chain and lifting arms daily.
Warning: Keep all personnel clear of the machine when it is in operation.
Caution: Always carefully watch the lifting arms and drums when it is in operation.
Caution: Never use the DGD-A / DGS-A if any damage or unusual noise is observed, if it is in need of repairs, or if it
seems to be malfunctioning. Notify your supervisor or maintenance personnel if you notice anything out of the
ordinary.
Ensure that all safety and warning labels stay in place and are legible. Refer to the labels page in this manual.
