VBT-60/80 Operating Procedures
9
2.2 VBT-80 Specifications
VBT-80 specifications and leading particulars are listed in Table 2.0
Table 2.0. VBT-80 Specifications
MODEL....................... VBT-80
TYPE ............................ Special-Purpose Test Equipment, portable 80 kV vacuum bottle tester
SIZE (inches) .............. 16.8 W by 3.5 H by 10.6 D (42.7 cm by 8.9 cm by 26.9 cm)
WEIGHT....................... 10 pounds (4.53 Kg)
INPUT POWER ........... 2 amps, 90-240 V ac, 50/60 Hz
OUTPUT VOLTAGE... 10 kV to 80 kV dc in 5,000-volt steps
OUTPUT RIPPLE
VOLTAGE.................... 3% max
DISCHARGE TIME ..... Maximum discharge time for internal high voltage is 0.3 seconds
DISPLAY...................... Backlit LCD, 2-lines by 16 characters
INDICATORS ............. Test failure indicator: LED is turned on if test current exceeds
the preset current threshold (100
?
A, 200
?
A or 300
?
A).
High Voltage Enable Indicator: LED is turned on when high voltage
is present at high voltage cable.
CONTROL ................... Single knob selector (turn-and-press selection)
COMPUTER
INTERFACE ................ RS-232C port, 19,200 Baud (Factory Calibration and Diagnostic)
ENVIRONMENT.......... Operating: -10°C to 55°C (15
?
F to +122
?
F)
Storage: -30°C to 70°C (-22
?
F to +158
?
F)
FURNISHED ITEMS ... One power cord, one ground cable, one 10-ft. high-voltage cable,
One 10-ft. high-voltage return cable.
OPTIONS ................... Transportation case included
WARRANTY................ One-Year Parts & Labor (Post-Warranty Service Contracts Available)
VBT-80 SPECIFICATIONS ARE SUBJECT TO UPGRADES AND MAY BE CHANGED WITHOUT PRIOR NOTICE.
