VBT-60/80 Operating Procedures
18
6.1.3. Change VBT Test Duration, Test Voltage and Test Current Threshold
The test duration can be set at 5 seconds, 10 seconds, 30 seconds, 1 minute, or 2 minutes.
The test voltage for the VBT-60 can be set from 10 kv DC to 60 kv DC with 5 kv DC steps.
The test voltages for the VBT-80 can be set from 10 kv DC to 80 kv DC with 5 kv DC steps.
Test current threshold can be set at 100
?
A or 200
?
A or 300
?
A.
Use the following steps to select test duration, test voltage and test current threshold.
Table 7. Set VBT Test Duration, Voltage, Current
STEP DESCRIPTION DISPLAY ACTION
1 Select SETUP mode MAIN:
21:02:00 Turn knob
2 Go to SETUP mode MAIN:
21:02:05 Press knob
3 Change time duration TIME: <5 Sec>
21:02:06 Turn knob to change time.
4 Select 10 second test
time TIME: <10 Sec>
21:02:07 Press knob to select
5 Change voltage
setting VLTG: <10 KV>
21:02:08 Turn knob to change
voltage
6 Select 20 KV test
voltage VLTG: <20 KV>
21:02:09 Press to select voltage
7 Change Current
threshold setting Thres: <100
? A>
21:02:10
Turn knob then press to
select
8 Return to Main Menu MAIN:
21:02:05 None
