j. The following screen will be displayed:
Type the Cos ϕ value using the keypad and then press the [ENTER] key.
k. The following screen will be displayed:
Select the rated secondary current by pressing the [1] key (5A) or [2] key (1A).
l. The following screen will be displayed showing a summary of the test parameters:
Press the
[START]
key to start the test.
m. If the selected test included a resistance test, the following screen will be displayed
momentarily:
The following screen will then be displayed:
NOTE
The “HIGH VOLTAGE PRESENT” light will be illuminated to indicate that high
voltage is present.
n. If the selected test included a ratio test, the following screen will be displayed
momentarily:
CABLES ENERGIZED:
1200V 1.0A X1-X2
RESISTANCE = 215.1
Ω
CABLES ENERGIZED:
1200V 1.0A X1-X2
DC RESISTANCE TEST
TEST 1 PARAMETERS:
1200V 1.0A X1-X2
“START” TO BEGIN
RATED SECONDARY CUR:
1. 5A 2.1A
ENTER COS ϕ:
(0.00 – 1.00)
0.0
