CVT-765 USER’S MANUAL REV 1
5
Table 2. Functional Descriptions of CVT-765 Controls and Indicators
Item
Number
Panel Markings Functional Description
1 GROUND Ground stud for connecting to sub-station ground
2 X X voltage connector
3 USB MEM USB Flash drive interface port
4 RS-232C RS-232C computer interface port
5
Back-lit LCD screen (128 x 64 pixels), viewable in direct light and low
light conditions
6
VOLTAGE
SELECTOR
Voltage selection switch
7
120/240 Vac, 4A, 50-60 Hz
Fuse: 250Vac, 5A Fast Blow
Input power connector and fused power switch with third-wire safety
ground
8 Rugged alpha-numeric keypad
9
7500VAC
PRESENT
7500VAC hazard warning LED. This LED will be lit when a test is
being performed to remind the user that 7500VAC is present.
10 H2 H2 voltage connector
11 H1 H1 voltage connector
12
“PUSH”
TO
ARM
Spring-loaded push button switch. Press and hold to initiate a test.
