REV 1 CVT-765 USER’S MANUAL

3.6

Working With Test Records

3.6.1. Viewing the Contents of the Working Memory

Whenever a test is performed or a test record is retrieved, the data is stored in the CVT-765’s
working memory. You can view the test data using the steps below:

a. Start from the “START-UP” menu:

Press the

[2]

key (SETUP).

b. The following screen will be displayed:

Press the

[3]

key (DISPLAY RECORD).

c. The basic test record information will be displayed as shown:

d. Press the

[Contrast ∨]

key. The test record details will be displayed as shown below:

Press the

[STOP]

key to return to the “START-UP” menu.
