CVT-765 USER’S MANUAL

REV 1

3.6.2. Saving Test Results to a Test Record

After performing a test, the user is presented the option to save the test results to the unit’s
Flash EEPROM or to a USB Flash Drive. If the test results are not saved immediately after
performing a test, they will still remain in the working memory and can be saved later, as long
as a new test has not been performed and the unit has not been turned off. Follow the steps
below to save the test results from the working memory to a test record (the following
procedure can also be used to re-save a restored test record to a new memory location or to a
USB Flash Drive):

a. Perform a test or restore a test record to the working memory (see section 3.6.3 and

3.6.4), and then start from the “START-UP” menu:

Press the

[2]

key (SETUP).

b. The following screen will be displayed:

Press the

[4]

key (SAVE/RESTORE RECORD).

1. RECORD ID
2. SET 50/60 HZ
3. DISPLAY RECORD
4. SAVE/RESTORE RECORD
5. SET TIME
6. set language

1. TEST TRANSFORMER
2. SETUP

TIME: 15:16:17

DATE: 05/17/11
