Herculito Operating Procedures
6
2.0 HERCULITO SPECIFICATIONS
Herculito specifications and leading particulars are listed in Table 1.
Table 1 Herculito Specifications
MODEL .........................
Herculito
TYPE................................
Special-Purpose Test Equipment, Portable, Low Resistance-Ohmmeter
SIZE (inches)..................
17” L by 13” W by 7” H (43.2 Cm x 33 Cm x 18.8 Cm)
WEIGHT ..........................
Less than 15 pounds (6.8 Kg)
RESISTANCE
RANGE ............................
1 micro-ohm to 300 milli-ohms
TEST CURRENT
RANGE ............................
80 Amperes to 100 Amperes, Auto ranging
DISPLAY .........................
Backlit LCD, 2-lines high by 16 characters Wide
ACCURACY ....................
± 1 % Reading, ± 1 Count
MEMORY.........................
Retain last 3 readings in memory during test
OPERATING POWER ...
5 amps, 90-230 Vac, 50/60 Hz.
PROTECTION .................
thermal-overload sensor and cutoff
COMPUTER INTERFACE .... RS-232C; 19200 Baud (Diagnostic Testing)
ENVIRONMENT .............
Operating: 0°C to 55°C; Storage: -40°C to 65°C
FURNISHED ITEMS.......
One power cord, one ground cable, two 45-ft. test lead cables,
and one test-cable carrying bag
WARRANTY....................
One-Year Parts & Labor (Post-Warranty Service Contracts Available)
HERCULITO SPECIFICATIONS ARE SUBJECT TO UPGRADES AND MAY BE CHANGED WITHOUT PRIOR NOTICE.
