TREND IQ251 - Manual (Page 12)

12 IQ251 Installation Instructions TG103483 Issue 3, 8/10/08
IQ251 Installation Instructions
IQ 251
RX TX
A D D R E S S
O N
4 Mounting in an Enclosure, ENCLS/...
1
Drill Wall
2
560 mm (22.04")
560 mm (22.04")
Open Door
Mount IQ25x on Backplate
5
tighten 4
screws
6
Replace Backplate
b a
b a c
5 Connecting to PC using Supervisor Port
Connect RS232 1
9 Way 'D type'
Female
CABLE/EJ101442
RJ11 SUPERVISOR
Configure Address 2
sUpervisor port addr = 1,4 to 9, 11 to 119
SET or
PowerTool
IQ Configuration Manual 90-1533
IQ251 Data Sheet TA102315
sUpervisor port addr = 0
IQ251
4
Remove Backplate
3
Mount on Wall
OR
No. 12
