SCVO, SCVI, SCCI, SCTI, SCDI
Installation Instructions
SCVO, SCVI, SCCI, SCTI, SCDI S Cards Installation Instructions TG103127 Issue 2/A 22/5/03
2 - 4
Trend Control Systems Ltd reserves the right to revise this publication from time to time and make changes to the content hereof without
obligation to notify any person of such revisions or changes.
Trend Control Systems Ltd P.O. Box 34 Horsham Sussex RH12 2YF Telephone 01403 211888 Fax 01403 241608 www.trend-controls.com
Installation
(continued)
Replace ENCLS/CMTRAY Cover
if ENCLS/CMTRAY fitted
21
Close Panel
22
I Q 2 4 1
I Q 2 4 1
Reconnect Supply to I/O
23
O
I
