IQ21x Installation Instructions TG200059 Issue 1/E 09/11/06
Installation Instructions
IQ21x
15
Close Panel
13
Download Strategy
4
Replacing the Battery
(Continued)
16
Reconnect Input power to I/O, Network
O
I
SET
IQ21x
X.IQ2
SET Manual TE200147
OR
9 F'D'
RJ11
IQ21x
IQ21X
also set time, day, date
Reset RAM
12
Complete Zero Address/Baud
Rate Switch Reset (Section 5
below, steps 6 to 11).
If not IQ2v3
(IQ2v3 will reset RAM
automatically)
IQ21x/USA:
The unit is UL rated as 'UL916,
listed open energy
management equipment'
If fitted in ENCLS/MBOX/IQ21x
14
Close MBOX
a
b
