6
QPHY-UWB-OM-E Rev C
INSTALLATION
The QPHY-UWB option is enabled through installation of an option key. If the option was purchased with the
oscilloscope, then the key will already have been installed and nothing further is required to gain access and
control of the option. If the option was purchased independently of the oscilloscope and needs installation, then
please follow the instructions in the next section.
Oscilloscope Option Key Installation
If an option key has not yet been purchased to enable the QPHY-UWB option, call LeCroy Customer Support to
place an order and receive the code.
Enter the key and enable the option as follows:
1. From the oscilloscope menu select Utilities
Utilities Setup...
2. Select the Options tab and click the Add Key button.
3. Enter the Key Code using the on-screen keyboard.
4. Restart the oscilloscope to activate the option after installation.
Oscilloscope Firmware Version:
In order to enable the features described in this documentation version 5.2.0 or later firmware should be installed.
If your oscilloscope has an earlier version of the firmware, please download the latest version from the LeCroy
website (
www.lecroy.com ) and install on oscilloscope. Note that you do not need to re-install the option keys when
you update the firmware.
