8.14 SendTlpType()
This function specifies more precise tuning (filtering in) for sending TLP packets to the script.
Format:
SendDllpType( tlp_type )
Parameters:
tlp_type Encoding of the TLP type. This parameter may be one of the following values:
TLP type values:
Constant TLP type
_TLP_TYPE_INVALID Invalid TLP types
_TLP_TYPE_MRD32 Memory Read Request, 32-bit address format
_TLP_TYPE_MRDLK32 Memory Read Request - Locked, 32-bit address format
_TLP_TYPE_MWR32 Memory Write Request, 32-bit address format
_TLP_TYPE_MRD64 Memory Read Request, 64-bit address format
_TLP_TYPE_MRDLK64 Memory Read Request – Locked, 64-bit address format
_TLP_TYPE_MWR64 Memory Write Request, 64-bit address format
_TLP_TYPE_IORD I/O Read Request
_TLP_TYPE_IOWR I/O Write Request
_TLP_TYPE_CFGRD_0 Configuration Read Type 0
_TLP_TYPE_CFGWR_0 Configuration Write Type 0
_TLP_TYPE_CFGRD_1 Configuration Read Type 1
_TLP_TYPE_CFGWR_1 Configuration Write Type 1
_TLP_TYPE_MSG Message Request
_TLP_TYPE_MSGD Message Request with Data payload
_TLP_TYPE_MSGAS Message for Advanced Switching
_TLP_TYPE_MSGASD Message for Advanced Switching with Data
_TLP_TYPE_CPL Completion
_TLP_TYPE_CPLD Completion with Data
_TLP_TYPE_CPLLK Completion for Locked Memory Read
_TLP_TYPE_CPLDLK Completion for Locked Memory Read with Data
_TLP_TYPE_MEMORY All Memory Request TLP types
_TLP_TYPE_IO All I/O Request TLP types
_TLP_TYPE_CONFIG All Configuration Request TLP types
_TLP_TYPE_MESSAGE All Message Request TLP types
_TLP_TYPE_COMPLETION All Completion TLP types
_ANY_TYPE All possible TLP types
Example:
SendTlpType( _TLP_TYPE_ID_MSG ); # Send Message Request TLPs to the script
…
SendTlpType( _TLP_TYPE_MEMORY ); # Send all Memory Request TLPs to the script
