Teledyne LeCroy Verification Script Engine Reference Manual Version 6.6x
22
7 Verification Script Engine Events
VSE defines a large group of trace “events” – on packet, link and split transaction levels – that can be
passed to a verification script for evaluation or retrieving and displaying some contained information. The
information about the type of event can be seen in in.TraceEvent. Please refer to the topic "Sending Functions" in
this manual for details about how to specify transaction levels and which events should be sent to verification
scripts.
7.1 Packet level events
The table below describes the current list of Packet level events (transaction level: 0) and value of in.TraceEvent:
Types of Packets
in.TraceEvent
Data Link Layer Packets (DLLP) _PKT_DLLP
Transaction Layer Packets (TLP) _PKT_TLP
Ordered Sets _PKT_ORDERED_SET
Link Conditions _PKT_LINK_CONDITION
7.2 Link Transaction level events
The table below describes the current list of Link Transaction events (transaction level: 1) and value of
in.TraceEvent:
Types of Link Transactions in.TraceEvent
Memory transactions _LINK_MEMORY
IO transactions _LINK_IO
Configuration transactions _LINK_CONFIG
Message transactions _LINK_MESSAGE
Completion transactions _LINK_COMPLETION
7.3 Split Transaction level events
The table below describes the current list of Split Transaction events (transaction level: 2) and value of
in.TraceEvent:
Types of Split Transactions in.TraceEvent
Memory transactions _SPLIT_MEMORY
IO transactions _SPLIT_IO
Configuration transactions _SPLIT_CONFIG
