Introduction
Use this document for quick installation and setup.
If you experience problems or need more information, see the Summit T3-16 User Manual on the Installation CD or at the
Teledyne LeCroy web site.
Summit T3-16
PCI Express Protocol Analyzer
Quick Start
Components
The analyzer package includes the following components:
•
Summit T3-16 analyzer box
•
AC Power Cable
•
USB and Ethernet cables
•
PETracer Software program CD-ROM
Depending on configuration, the package may also include:
•
One (for x8 recording) or two (for x16 recording) probe
cables
•
Slot interposer
•
MidBus Probe kit
Please see the Summit T3-16 User Manual on the
installation CD for component specifications and further
details.
Summit T3-16 Protocol Analyzer
1
2
Unpacking the Analyzer
Inspect the received shipping container for any damage. Unpack the container and account for each of the system
components listed on the accompanying packing list. Visually inspect each component for absence of damage.
In the event of damage, notify the shipper and Teledyne LeCroy. Retain all shipping materials for shipper’s inspection.
3
