24.2 InputBox()
Displays a prompt in a dialog box, waits for the user to input text or click a button, and returns
a CSL list object ( see CSL manual for details about list objects ) or string containing the contents of
the text box.
Format :
InputBox( prompt, title, default_text, return_type )
Parameters:
prompt - Required. String expression displayed as the message in the dialog box.
title - Optional. String expression displayed in the title bar of the dialog box. If you omit
title, the script name is placed in the title bar.
default_text - Optional. String expression displayed in the text box as the default
response if no other input is provided. If you omit default, the text box is
displayed empty.
return_type – Optional. It specifies the contents of the return object.
The return_type argument values are:
Constant
Value
Description
_IB_LIST
0
CSL list object will be returned ( by Default ).
_IB_STRING
1
String input as it was typed in the text box
Return Values:
Depending on the return_type argument this function returns either CSL list object or the text
typed in the text box as it is.
In case of return_type = _IB_LIST ( by default ) the text in the text box is considered as a set of list
items divided by ',' ( only hexadecimal, decimal and string items are currently supported ).
i.e. text :
Hello world !!!, 12, Something, 0xAA, 10, "1221"
Will produce a CSL list object ( 5 items ):
list = [ "Hello world !!!", 12, "Something", 0xAA, 10, "1221" ];
list [0] = "Hello world !!!"
list [1] = 12
list [2] = "Something"
list [3] = 0xAA
list [4] = 10
list [5] = "1212"
NOTE: Although the dialog box input text parser tries to determine a type of list item
automatically, a text enclosed in quote signs "" is always considered as a string.
