Verification Script Engine Reference Manual
23
10.12 SendPrimitive()
This function specifies more precise tuning for sending primitive frames.
Format :
SendPrimitive( primitive )
Parameters:
primitive – dword primitive value. This parameter may be one of the following values:
Primitive values:
Constant
Primitive
_IDLE Idle Primitive
_R_RDY Receiver Ready
_VC_RDY Virtual Circuit Ready
_ARB_yx Arbitrate
_ARB_val Arbitrate
_OPN_yx Open full-duplex
_OPN_yy Open full-duplex
_OPN_yr Open selective replicate
_OPN_fr Open broadcast replicate
_CLS Close
_MRK_tx Mark
_DHD Dynamic Half-Duplex
_OLS Offline
_NOS Not Operational
_LR Link Reset
_LRR Link Reset Response
_LIP_F7_F7 Loop Initialization--F7,F7
_LIP_F8_F7 Loop Initialization--F8,F7
_LIP_F7_x Loop Initialization--F7,x
_LIP_F8_x Loop Initialization--F8,x
_LIP_yx Loop Initialization--reset
_LIP_fx Loop Initialization--reset all
_LIP_ba Loop Initialization--reserved
_LPE_yx Loop Port Enable
_LPE_fx Loop Port Enable all
_LPB_yx Loop Port Bypass
_LPE_fx Loop Port Bypass all
_SYN_x Clock Synchronization
_SYN_y Clock Synchronization
_SYN_z Clock Synchronization
Example:
SendPrimitive( _R_RDY ); # - send ‘Receiver Ready’ primitive
10.13 SendFCPSeq ()
This function specifies more precise tuning for FCP-SCSI sequences.
