PP065/PP066 Passive Probe
10 922225-00 Rev A
Specifications
PP065 PP066
Nominal Characteristics
(guaranteed by design, but do not have associated tolerances)
Input Dynamic Range ± 15 V
rms
System Attenuation 100:1 ±1% ÷10 and ÷20 ±1% plus 50 Ω
termination tolerance
Input Resistance 5 kΩ ±0.5% ÷10 500 Ω ±1% plus 50 Ω
termination tolerance
÷20 1 kΩ ±1% plus 50 Ω
termination tolerance
Coupling 50 Ω 50 Ω
Maximum non-destruct
input voltage
30 V (DC + peak AC)
Typical Characteristics
(performance not guaranteed, but representative of the average performance from a
sample of several probes)
System Bandwidth (-3 dB) 1 GHz DC to 7.5 GHz
Rise Time 47 psec
Input Capacitance 2 pF ±5% 0.25 pF
Environmental Characteristics
Operating Temperature 0
o
to 50
o
C at 80% RH 0
o
to 45
o
C at 80% RH
Humidity ≤ 80% at 31
o
C max. ≤ 80% at 31
o
C max.
Altitude up to 3000 m (9850 ft) up to 3000 m (9850 ft)
Physical Characteristics
Weight 38 g * 26.5 g (0.94 oz) †
Cable Length 1.4 m 1 m ±20 mm
* Probe plus accessories.
† Probe only.
