Instruction Manual
920876-00 Rev A 3
Specifications
Model Attn.
Input
Imped. B/W
Rise
Time Length
Compensation
Range
R (MΩ) C (pF) (MHz) (ns) (m) (pF)
PP017 10x 10 12 250 1.4 1.3 10 - 30
PP018 10x 10 10 500 0.7 1.3 6 - 22
Attenuation Ratio ................................... 10x (10:1) 10:1 ±0.5%
Max. Input Voltage ................................. 600 V CAT I or 300 V CAT II (DC + peak AC)
................................................................... Derated with Frequency (see Derating Curve)
Pollution Degree .................................... Pollution Degree 2 (as defined in EN 61010-031)
Max. Operating Temp ........................... 0° to +50 C°
Humidity .................................................. 85% RH or less (at 35° C)
WARNING
To reduce risk of fire or electric shock, do not exceed the voltage or
category ratings of the probe.
Definitions:
Measurement Category I (CAT I) is for measurements performed on circuits not directly connected
to mains.
Measurement Category II (CAT II) is for measurements performed on circuits directly connected to
the low voltage installation. Examples are on household appliances, portable tools, and similar
equipment.
Pollution Degree 2 refers to an operation environment where normally only dry non-conductive
pollution occurs. Temporary conductivity caused by condensation must be expected.
