PP017/PP018 Passive Probe
2 920876-00 Rev A
Terms and Symbols
The following terms appear in this manual:
WARNING
Warnings identify conditions or practices that could result in injury
or loss of life.
The following symbols may appear on the product:
DANGER High Voltage
ATTENTION Refer to Manual
DOUBLE INSULATION
PROTECTIVE (EARTH) TERMINAL
Introduction
The Teledyne LeCroy PP017 and PP018 are passive high impedance
voltage oscilloscope probes designed and calibrated for use with
general purpose oscilloscopes having an input impedance of 1 MΩ
shunted by 16 pF. However, they may be compensated for use with
instruments having an input capacitance between 10 to 30 pF. They are
compatible with oscilloscopes that automatically detect probe
attenuation and adjust their readout accordingly.
WARNING
To avoid electric shock, keep fingers behind the probe’s finger
guard during use.
