Step Description Intermediate Data Test Result
1. Output Voltage
V
2. Output Voltage after AutoZero V
3. Output Zero (Test limit ≤ 10 mV)
mV
Step Description Intermediate Data Test Result
4. Probe Low Range Input Voltage V
5. Probe Low Range Output Voltage V
6. Corrected Low Range Output Voltage V
7. Low Range Attenuation Error
(Test limit ≤ 2%)
%
Step Description Intermediate Data Test Result
8. Probe High Range Input Voltage
V
9. Probe High Range Output Voltage V
10. Corrected High Range Output Voltage V
11. High Range Attenuation Error
(Test limit ≤ ±5.0%)
%
Step Description Intermediate Data Test Result
12. System rise time
ps
13. Rise time with probe ps
14. Probe Rise Time
psec
